Air Shower Clean Room with Electronic Interlock
Product Features of Air Shower Clean Room with Electronic Interlock:
Features of Air Shower Clean Room with Electronic Interlock:
1.Air Shower Clean Room with Electronic Interlock, Intelligent control chip, intelligent programmable control, double-door electronic interlock, infrared induction shower, clear indicator light, emergency stop switch, reflecting stronger professionalism, convenience and safety.
2. Air Shower Clean Room with Electronic Interlock,Selected plates and accessories are made of high-quality A3 cold-rolled steel plate with multi-layer pickling and plastic spraying or all stainless steel, high-strength wear-resistant stainless steel bottom plate and stainless steel nozzle, which play a good role in corrosion resistance and rust resistance;
3.Air Shower Clean Room with Electronic Interlock, Energy saving and power saving, equipped with transparent windows and LED electronic lighting, the uniform light consumes less energy. High-efficiency and energy-saving fans are used.
4.Air Shower Clean Room with Electronic Interlock, Good illuminance, using high-performance LED electronic lighting, good illuminance.
5. Air Shower Clean Room with Electronic Interlock,The design is scientific and reasonable. The Air Shower Clean Room with Electronic Interlock is supplied with air by the fan, enters the static pressure box through the primary filter, and then is filtered by the high-efficiency filter. Effectively remove the dust attached to the surface of people or carried items, and the blown dust will flow back into the primary air filter, and so on. The combination of the primary and high-efficiency filter can not only better filter the air, but also prolong the service life of the filter.
specification of Air Shower Clean Room with Electronic Interlock
| 类型 技术参数Type Specification | 单人单吹 1 person SHW-1200-1 | 单人双吹 1-2 person SHW-1300-1 | 多人双吹 3-6 person SHW-1300-3 |
| 外形尺寸 External Dimension W*L*H(mm) | 1200*1000*2170 | 1300*1000*2170 | 1300*3000*2170 |
| 风淋区尺寸 Air shower area size W*L*H(mm) | 800*860*2000 | 800*860*2000 | 800*2860*2000 |
| 喷口风速（m/s） Nozzle wind speed（m/s） | ≥25 | ≥25 | ≥25 |
| 喷嘴数量 Number of Nozzle | 6 | 12 | 36 |
| 风淋时间（s) Blowing time（s) | 0~90（可调）（Adjustable） | ||
| 过滤器 Filter | 高效过滤器（效率≥99.95%）初效过滤器，可清洗化纤滤料≥（5μm计数率≥95%） HEPA filter（Efficiency≥99.95%）Pre filter，Washable chemical fiber filter media≥（at5μm efficiency≥95%） | ||
| 电源 Power Supply | 380v 50Hz | ||
| LED照明灯 LED Light | 8W=1 | 8W=1 | 8W=3 |
| 功耗（KW） Power（KW） | 0.6 | 1.5 | 3.5 |
| 净重（kg） Net weight（kg） | 355 | 412 | 1150 |
