Clean room Gel seal Hepa Box DOP Hepa box
Product Introduction of Clean room Gel seal Hepa Box DOP Hepa box:
Product Features of Clean room Gel seal Hepa Box DOP Hepa box:
1. The knife edge type is inserted into the gel glue of the liquid tank filter to achieve sealing, which avoids the leakage of the supply air from the installation place, and pass the integrity test of DOP dust generation at one time.

2. Install 2 DOP connectors, one for dust generation and one for detection. It is convenient for users to detect and test the pressure drop of the high-efficiency filter in the air of the filter facing the DOP of a single filter.

3. The hose connected under the quick release joint is passed to the bottom of the box to ensure the uniform dust concentration upstream of the filter.
Specification of Clean room Gel seal Hepa Box DOP Hepa box:

尺寸 Dimensions (mm)	额定风量 Rated airflow (m3/h)	接口尺寸Connection size（mm）	散流板尺寸 Diffuser size（mm）	过滤器尺寸Filter size （mm）
482*482*250	500	200*200	528*528*15	412*412*93
701*586*250	1000	320*200	747*632*15	631*516*93
828*701*250	1500	320*250	874*747*15	758*631*93
1096*701*250	2000	500*200	1142*747*15	1026*631*93
