Stainless steel High Efficiency Blower
Features of Stainless steel High Efficiency Blower: 1. About Stainless steel High Efficiency Blower,The airflow distribution is more reasonable, and the latest Japanese technology design is adopted to make the airflow distribution more reasonable, and the box structure is simpler and more reliable. Stainless steel High Efficiency Blower is a terminal filter device used for the renovation and new construction of 1000-300000-level clean rooms, and it is the key equipment to meet the purification requirements；
Features of Stainless steel High Efficiency Blower: 1. About Stainless steel High Efficiency Blower,The airflow distribution is more reasonable, and the latest Japanese technology design is adopted to make the airflow distribution more reasonable, and the box structure is simpler and more reliable. Stainless steel High Efficiency Blower is a terminal filter device used for the renovation and new construction of 1000-300000-level clean rooms, and it is the key equipment to meet the purification requirements；
2. High-quality plates are used, and the box is made of cold-rolled steel plates with paint or stainless steel;
3. Well-designed diffuser, based on the principle of aerodynamics, the designer's well-designed diffuser ensures the jetting speed of the airflow and prevents the generation of eddy currents;
4. The air supply mode is flexible, the flange mouth is square or round, the structure is compact, the sealing performance is reliable, and thermal insulation cotton can be provided.
5. Applicable fields of Stainless steel High Efficiency Blower: suitable for non-uniform flow clean rooms of various grades and various roof structures.
Specification of Stainless steel High Efficiency Blower:
| 类型 Type | 箱体 安装尺寸 Box mounting dimensions（mm） | 过滤器尺寸 Filter dimensions（mm） | 额定风量 Rated airflow (m3/h) | 进风管 尺寸 Dimensions of inlet duct（mm） | 风管 连接尺寸Air duct connection dimensions（mm） | 散流板尺寸Size of diffuser plate（mm） | |
| 侧面送风 Sidewall air supply | 顶面送风 Top air supply | ||||||
| 320 | 320 | 330*330*400 | 320*320*90 | 500 | 200*200 | 250*250 | 390*390*20 |
| 484 | 484 | 494*494*400 | 484*484*90 | 1000 | 320*200 | 370*250 | 554*554*20 |
| 630 | 630 | 640*640*450 | 630*630*90 | 1500 | 320*250 | 370*300 | 700*700*20 |
